Technical specificationsLT Series (LT500 / LT1000(PRO) / LT1500(PRO) + LT500-110 / LT1000-110) product image

Line-interactive backup, LiFePO4, 220 V + 110 V

Highidea LT Series — Line-Interactive Backup UPS (LiFePO4)

The LT Series is a compact line-interactive UPS with internal Class-A LiFePO4 batteries for 220 V office loads and 110 V marine or imported equipment, with AVR regulation and approximately 4–8 ms transfer.

Capacity
LT500 600VA/360W · LT1000 1000VA/600W · LT1500 1500VA/900W; 110V line — LT500-110 650VA/360W · LT1000-110 1000VA/600W
Topology
Line-interactive / backup with AVR; simulated sine output
Transfer Time
~4–8 ms
Chemistry
A-grade LiFePO4
Runtime Table
LT500: 50W=145 · 100W=78 · 200W=32 · 300W=4 | LT1000: 50W=235 · 100W=105 · 200W=80 · 300W=5 | LT1500: 50W=420 · 100W=210 · 200W=154 · 300W=5
Request a quoteRequest datasheet
CE-LVD scope available2-year UPS warranty

Confirm host, battery, runtime and document scope for the exact configuration

Capacity

LT500 600VA/360W · LT1000 1000VA/600W · LT1500 1500VA/900W; 110V line — LT500-110 650VA/360W · LT1000-110 1000VA/600W

Topology

Line-interactive / backup with AVR; simulated sine output

Chemistry

A-grade LiFePO4

Config

batt V LT500 12V, LT1000/1500 24V; cells 4S/8S; internal WH 166.4/332.8/499.2; 110V — LT500-110 12V/15AH, LT1000-110 24V/15AH

Technical data

LT Series (LT500 / LT1000(PRO) / LT1500(PRO) + LT500-110 / LT1000-110) specifications.

Compare the electrical, battery, monitoring, environmental and compliance data for this product family.

01Electrical
CapacityLT500 600VA/360W · LT1000 1000VA/600W · LT1500 1500VA/900W; 110V line — LT500-110 650VA/360W · LT1000-110 1000VA/600W
TopologyLine-interactive / backup with AVR; simulated sine output
Input220 VAC, range 140–300 VAC, 50/60 Hz auto (110 V line: 110 VAC, range 81–134 VAC)
Output220 V ±10% (battery mode); 110 V line: 110 V ±10%
Transfer Time~4–8 ms
02Battery
ChemistryA-grade LiFePO4
Configbatt V LT500 12V, LT1000/1500 24V; cells 4S/8S; internal WH 166.4/332.8/499.2; 110V — LT500-110 12V/15AH, LT1000-110 24V/15AH
Lifefloat >10 yr, cycle >1200
Charge10 h to 90% (110V line: 9 h)
Runtime TableLT500: 50W=145 · 100W=78 · 200W=32 · 300W=4 | LT1000: 50W=235 · 100W=105 · 200W=80 · 300W=5 | LT1500: 50W=420 · 100W=210 · 200W=154 · 300W=5
03Management & Monitoring
InterfacesPRO version only: mobile monitor / central / SNMP
04Environment & Mechanical
Operating Temperature0–+40 °C (battery not below 0)
Storage Temperature−10–+45 °C
Noise<40 dB
Dimensions Weightnet W×H×D mm / kg — LT500 280×100×144 (3.4) · LT1000/1500 370×138×165 (7.4/9.5); 110V — LT500-110 (4.2) · LT1000-110 (9)
05Compliance & Warranty
CELT500–1500 and LT500/1000-110 model ranges are explicitly listed on CE certificates 2026AT0427548 and 2026AT0511577
Battery Un38 3UN 38.3 report TCT200602B052 applies specifically to the LT500 lithium UPS
WarrantyUPS main unit: 2 years; battery warranty depends on capacity (7–17 Ah: 1 year; 24–200 Ah: 2 years)

Request the full user manual & datasheet

Selection guide

Is this the right model for you?

Quick pointers to confirm fit, or steer you to a sibling model.

  • Choose the LT Series (LT500 / LT1000(PRO) / LT1500(PRO) + LT500-110 / LT1000-110) when its power range, format and operating role match your application.
  • Provide capacity, input/output voltage, runtime, installation format and destination-market document requirements for final model selection.

Recommended for

Where the LT Series (LT500 / LT1000(PRO) / LT1500(PRO) + LT500-110 / LT1000-110) performs.

Marine and shipboard environment
Marine / ECDIS (110 V — LT1000-110, flagship marine model)
LT Series (LT500 / LT1000(PRO) / LT1500(PRO) + LT500-110 / LT1000-110) can be configured for this application; final sizing depends on the load, runtime and site conditions.
View solution
Office / desktop backup
Office / desktop backup
LT Series (LT500 / LT1000(PRO) / LT1500(PRO) + LT500-110 / LT1000-110) can be configured for this application; final sizing depends on the load, runtime and site conditions.
View solution
Import-export 110 V equipment
Import-export 110 V equipment
LT Series (LT500 / LT1000(PRO) / LT1500(PRO) + LT500-110 / LT1000-110) can be configured for this application; final sizing depends on the load, runtime and site conditions.
View solution

FAQ

Frequently asked questions

What should I provide to select the right LT Series (LT500 / LT1000(PRO) / LT1500(PRO) + LT500-110 / LT1000-110)?

Share the load in watts or VA, input and output voltage, required runtime, installation format, site conditions and destination market. Our team will match the product, battery and monitoring options to the application.

Can I request a datasheet for the LT Series (LT500 / LT1000(PRO) / LT1500(PRO) + LT500-110 / LT1000-110)?

Yes. Contact sales with the required rating and destination market to receive the applicable datasheet, manual and compliance-document list.

Start a project

Configure a LT Series (LT500 / LT1000(PRO) / LT1500(PRO) + LT500-110 / LT1000-110) for your site.

Tell us the load, voltage, runtime, site conditions and destination. Sales will confirm the host, battery and configuration-specific document scope.
